Traxxas 83424-4-R5 4-Tec 2.0 Brushless Chassis

TraxxasModel 83424-4

Available to order

4-Tec 2.0 Brushless Chassis

On road chassis · Battery & charger sold separately

Scale
1/10
Drive
AWD
Power
Brushless
Top speed
50+ mph

Battery and charger sold separately — see Complete your setup.

$299.95 USD

Free standard shipping Contiguous US · in-stock orders ship in 1–2 business days
  • Ships in 1–2 business daysIn-stock orders leave Houston, TX by UPS or USPS. Free standard shipping on $99+.
  • Free store pickupSouthwest Fwy, Houston. We email when it's ready. Usually ready within 24 hours on days we're open.
  • Genuine parts, 30-day returnsEverything comes through authorized dealer accounts. Unopened items can come back within 30 days.
Shipping & pickup

Free standard shipping covers the contiguous 48 states, big trucks included; orders under $99 pay $5.95–$8.95. Tracking is emailed when your order leaves. Batteries ship ground only and can't go to P.O. boxes, APO/FPO, Alaska or Hawaii. Full shipping policy

Picking up in Houston? Choose Pick up at checkout and wait for our ready-for-pickup email.
Returns

30 days from delivery on new, unopened items. Opened-but-unused items may carry a 15% restocking fee; batteries, chargers, powered electronics and painted bodies are final sale once opened. Full refund policy
Warranty & support

Everything we sell is genuine and covered by the manufacturer's warranty (Traxxas, Horizon Hobby and the other brands we carry). If something arrives defective, contact us within 7 days and we'll make it right. Fitment or upgrade questions? Call 832-288-4789 or email support@rchobbyshop.com.

Part # 83424-4-R5 · Traxxas model 83424-4

Complete your setup

Everything the 4-Tec 2.0 Brushless Chassis needs to run

The 4-Tec 2.0 Brushless Chassis runs on a 2s–3s LiPo. NiMH is not supported. Battery and charger are sold separately. It also needs a 200 mm body, sold separately. Choose how you want to cover them; nothing goes in your cart until you press Add.

Which battery? Batteries and chargers, explained

1 Batteries & charger Required · choose one
The 2872X 5000 mAh 3s battery and the 2970 charger in one box.Charger: Traxxas recommendedSaves $9.95 vs. separately
$139.95
Uncheck anything you already own. Charger: Traxxas recommended
$149.90
The 2843X 5800 mAh 2s battery and the 2970 charger in one box. The 4-Tec 2.0 Brushless Chassis takes 2s–3s LiPo.
$129.95
$0
2 Transmitter batteries Required
The transmitter takes four AA batteries. Uncheck if you have them.
$4.95

Optional extras are never added for you: Upgrades for the 4-Tec 2.0 Brushless Chassis

Overview

The 4-Tec® 2.0 Brushless chassis provides the ultimate high speed driving experience with a low-CG chassis for a crisp, responsive feel.

The Velineon® 3s brushless power system puts out massive power for four-wheel, tire-spinning acceleration and incredible 50+ mph top speed, and a finely tuned suspension keeps the wheels glued to the pavement.

4-Tec's adjustable wheelbase and body mounts accommodate almost any 200 mm body, allowing nearly infinite custom body options.

Features

  • 35+ mph with 2s LiPo. 50+ mph with 3s LiPo (no gearing change required)
    High-speed capable
  • Adjustable Body Mounts and Chassis
    Body posts adjust forward and backward, left and right; Wheelbase can be lengthened or shortened by 3 mm; Accommodates most 200 mm bodies; Replica brake discs with red calipers
  • Velineon® VX3 Waterproof Electronic Speed Control
    Three programmable drive profiles (Sport Mode, Race Mode, Training Mode); Traxxas EZ-Set® one-button setup; Real-time telemetry via Traxxas Link™; High-Resolution Linear Braking; Compatible with 2s and 3s LiPo batteries
  • Velineon V3300 Brushless Motor
    Ultra high-temperature sintered Neodymium magnets; 3300 Kv optimized for 1/10th scale; 3 mm output shaft; Internal & external cooling fans; Low-maintenance design
  • TQi™ Sport 2.4 GHz 2-Channel Radio System
    Removable grip adapter; High-output signal; Simple one-button programming; 30-model memory; 3-channel micro receiver
  • Traxxas Stability Management® (TSM)
    Improves straight line acceleration and braking; Maintains steering composure; Never dulls throttle; Activated or deactivated from transmitter
  • Steering
    2057 waterproof, metal-gear servo with full metal gear train; Integrated servo saver
  • Low Center of Gravity (Low CG) Chassis
    Positions weight low for improved handling; Smooth underside resists drag; Modular interlocking chassis pieces
  • Adjustable Battery Hold Down
    Easy, secure battery installation; Swivels for different height batteries; Locks securely
  • High Performance Suspension
    Captured links; Geometry tuned for precise handling; Dual rear camber link mounts
  • Driveline
    Full-time shaft driven 4-wheel drive; Steel center driveshaft with center bearing support; Direct drive; Sealed differentials
  • Springs and Shocks
    Fully adjustable oil-filled Ultra Shocks™ with X-ring technology; Red powder coated shock springs
  • Wheels and Tires
    Black chrome multi-spoke wheels with lug nut detail; High-performance street tires; Staggered street tires larger in rear
  • Rubber-Sealed Ball Bearings
    Throughout vehicle

What's in the box

  • 4-Tec 2.0 Brushless Chassis
  • TQi Sport 2.4 GHz Radio System
  • High Quality Maintenance Tools

What you'll need

  • Body Standard 200 mm body
  • Battery Pack 4-Tec 2.0 Brushless requires a single 2-cell or 3-cell LiPo battery (NiMH not supported)
  • Charger The Traxxas EZ-Peak® charger #2970 is recommended for easy and fast charging performance
  • Alkaline Batteries Four AA alkaline batteries for the transmitter

See Complete your setup below

Specifications

Specifications, part 1 of 2
Scale 1/10
Type On-Road Car
Length 14.94 inches (379 mm)
Width 7.9 inches (200 mm)
Height 2.43 inches (62 mm)
Weight 2.83 lbs (1.28 kg)
Wheelbase 10.1 inches (256 mm)
Front Track 7.7 inches (196 mm)
Rear Track 7.9 inches (200 mm)
Ground Clearance 0.3 inches (9 mm)
Driveline Shaft-driven 4WD
Transmission Single speed direct drive
Specifications, part 2 of 2
Differential Sealed, hardened steel bevel, limited slip
Gear Pitch 48
Top Speed 50+ mph
Motor Velineon V3300 (patent pending); Sensorless brushless; 7.48 ounces (212 g); 3.15 inches (80 mm) length; 1.53 inches (39 mm) diameter; 3 mm shaft; 3.5 mm Bullet connector
ESC VX3 Electronic Speed Control; Brushless; 2-cell or 3-cell LiPo; 2.40″ x 2.09″ x 1.69″; 4.20 ounces (119 g); 6.0 volts BEC; 3.5 mm bullet motor connectors; Traxxas High-Current battery connectors
Transmitter TQi™ Sport 2.4 GHz 2-channel
Receiver 3-channel micro receiver with fail-safe security
Servo 2057 waterproof metal-gear
Battery Single 2-cell or 3-cell LiPo (NiMH not supported); 158 mm X 46 mm X 23 mm or 26 mm
Charger Traxxas EZ-Peak® charger #2970 recommended
Transmitter Power 4 AA alkaline batteries
Skill Level 1

Compare

How the 4-Tec 2.0 Brushless Chassis compares

Similar models we carry, side by side.

This model 4-Tec 2.0 Brushless ChassisModel 83424-4$299.95
4-Tec 2.0 Nissan 240SX BrushlessModel 93424-4$349.95
4-Tec Drift Ford MustangModel 105237-4$299.95
4-Tec Drift Nissan 240SXModel 105247-4$299.95
TypeOn-Road CarOn-Road CarDrift CarDrift Car
Scale1/101/101/101/10
Size (L × W × H)14.9 × 7.9 × 2.4 in18.4 × 8.5 × 5.2 in18.2 × 7.9 × 5.2 in18.4 × 8.5 × 5.2 in
Weight2.83 lb2.28 lb3.35 lb2.28 lb
Skill level1111
Top speed50+ mph50+ mphUnder 30 mph—
In the boxBattery & charger sold separatelyBattery & charger sold separatelyBattery & charger sold separatelyBattery & charger sold separately
Runs onA 2s–3s LiPoA 2s–3s LiPoA 2s LiPo or a 7-cell NiMHA 2s LiPo or a NiMH battery
Ready to run$444.85completer 2970-3S + AA$494.85completer 2970-3S + AA$434.85completer 2992 + AA$434.85completer 2992 + AA
You’re hereViewViewView

Specs as Traxxas prints them. Ready to run = the vehicle + the completer pack (battery and charger in one box) listed for that model + AA batteries for the transmitter, at our prices today; other battery options are on each model’s page. Nitro models also need fuel, bought locally. New to RC? How to read this table
