Traxxas 103076-4 Spartan SR
Orange
$449.95 USD
Skip to product information
Available to order
TraxxasModel 103076-4
Spartan SR
Deep v race boat · Battery & charger sold separately
- Scale
- 36 in
- Drive
- Marine drive
- Power
- Brushless
- Top speed
- 50+ mph
Battery and charger sold separately — see Complete your setup.
$449.95 USD
- Ships in 1–2 business daysIn-stock orders leave Houston, TX by UPS or USPS. Free standard shipping on $99+.
- Free store pickupSouthwest Fwy, Houston. We email when it's ready. Usually ready within 24 hours on days we're open.
- Genuine parts, 30-day returnsEverything comes through authorized dealer accounts. Unopened items can come back within 30 days.
Shipping & pickup
Free standard shipping covers the contiguous 48 states, big trucks included; orders under $99 pay $5.95–$8.95. Tracking is emailed when your order leaves. Batteries ship ground only and can't go to P.O. boxes, APO/FPO, Alaska or Hawaii. Full shipping policy
Picking up in Houston? Choose Pick up at checkout and wait for our ready-for-pickup email.
Returns
30 days from delivery on new, unopened items. Opened-but-unused items may carry a 15% restocking fee; batteries, chargers, powered electronics and painted bodies are final sale once opened. Full refund policy
Warranty & support
Everything we sell is genuine and covered by the manufacturer's warranty (Traxxas, Horizon Hobby and the other brands we carry). If something arrives defective, contact us within 7 days and we'll make it right. Fitment or upgrade questions? Call 832-288-4789 or email support@rchobbyshop.com.
Part # 103076-4-ORNG · Traxxas model 103076-4
Complete your setup
Everything the Spartan SR needs to run
The Spartan SR runs on two 2s–3s LiPo packs or two 7-cell NiMH packs. Battery and charger are sold separately. Choose how you want to cover them; nothing goes in your cart until you press Add.
Optional extras are never added for you: Upgrades for the Spartan SR
Overview
Spartan® SR: 1/10 scale brushless, self-righting, race boat with waterproof electronics. Ready-To-Race® with TQi™ 2.4 GHz 2-channel radio system, VXL-6s™ Marine speed control, Velineon® 540XL Marine brushless motor, and clipless deep-V hull. Requires: batteries and charger.
Extreme Velineon brushless horsepower delivers the muscle you want with the reliability you expect from Traxxas.
The high-output Traxxas TQi 2.4 GHz radio system delivers superior range, precision, and control.
TSM® acts like a reassuring hand when you need it to help harness Spartan SR's brutal 6s power for maximum acceleration and top-speed passes.
Spartan SR's electronics and power system bolt securely to the rigid tray for easy removal and maintenance.
Spartan SR's new battery tray relocates batteries centrally to the lowest part of the hull for drastically improved stability.
Read more Show less
Features
- 36″ Reinforced Deep-V HullMade from lightweight vacuum-formed ABS with self-righting flood chamber, pre-applied graphics, and quick-release electronics tray
- Rigid Injection-Molded Clipless HatchFour Twist-Lock® hatch nuts with tool, foam seal keeps water out, includes optional tool-free wingnuts
- Up to 50 MPH with Dual 3s LiPo Batteries
- VXL-6s™ Marine Electronic Speed ControlWater-cooled case, three drive profiles (Sport Mode, Race Mode, Training Mode™), built-in two-stage low-voltage detection
- Velineon® 540XL Brushless MotorUltra high-temperature sintered Neodymium magnets, 1800 kV, 5 mm output shaft, water-cooled jacket
- Traxxas Stability Management® (TSM)Improves straight line acceleration, adjusts from off to 100% assistance
- TQi™ 2.4 GHz Radio System2-channel transmitter, 5-channel micro receiver with fail-safe security and integrated telemetry ports
- Extra-Long 218 mm Battery TrayCentralizes battery weight, allows fore and aft positioning, accommodates multiple configurations
- DrivelineHeavy duty 4.7 mm diameter flex shaft, quick-release motor collet, blue-anodized aluminum drive strut
- SteeringWaterproof digital 2056 servo, blue-anodized aluminum rudder with water pickup
- Precision-Cut Stainless Steel Trim Tabs and Turn Fins
- Stainless Steel Hex Hardware Used Throughout
What's in the box
- Spartan SR with VXL-6s Marine ESC and 1850 Kv motor
- TQi 2.4 GHz radio system
- Boat stand
- Hatch nut tool
- Optional wingnuts
What you'll need
- Batteries Spartan SR requires dual 7-cell NiMH or dual 2s or 3s LiPo batteries
- Charger The Traxxas EZ-Peak® 3s Dual charger 2972 is recommended for easy and fast charging performance.
- AA Alkaline Batteries Four AA alkaline batteries for the transmitter
Specifications
| Scale | 1/10 |
|---|---|
| Type | Boat |
| Speed | 50+ mph with two 3-cell LiPo batteries |
| Skill Level | 2 |
| Weight | 5.29 pounds (2.39 kg) |
| Length | 40.8 inches (1037 mm) |
| Width | 9.5 inches (243 mm) |
| Height | 7.2 inches (183 mm) |
| Drive System | Direct drive, 4.7 mm flex cable |
| Outdrive | Adjustable aluminum |
| Hull Length | 36.5 inches (927 mm) |
| Dead Rise Angle | 26 degrees |
| Beam | 9.5 inches (243 mm) |
|---|---|
| Hull Type | Composite Deep-V |
| Steering Servo | 2056 high-torque waterproof |
| Radio System | TQi™ 2.4 GHz 2-channel transmitter with TSM® receiver |
| Motor | Velineon® 540XL Marine (sensorless brushless, 1800 kV, 5 mm shaft) |
| Motor Weight | 13.62 ounces (386 g) |
| Motor Length | 4.07 inches (103 mm) overall, 3.25 inches (82 mm) can |
| Motor Diameter | 1.42 inches (36 mm) |
| ESC | Velineon® VXL-6s Marine (brushless) |
| ESC Weight | 7.30 ounces (207 g) |
| ESC Case Size | 2.28 x 2.83 x 1.81 inches (58 x 72 x 46 mm) |
Compare
How the Spartan SR compares
Similar models we carry, side by side.
| Spec | |||
|---|---|---|---|
| Type | Boat | — | Boats |
| Scale | 1/10 | 1/10 | 1/10 |
| Size (L × W × H) | 40.8 × 9.5 × 7.2 in | 29.8 × 7.6 × 5.9 in | 23.8 × 5.8 × 3.3 in |
| Weight | 5.29 lb | 3.66 lb | 1.75 lb |
| Skill level | 2 | — | 1 |
| Top speed | 50+ mphwith two 3-cell LiPo batteries | 40+ mph | Under 30 mph |
| In the box | Battery & charger sold separately | Battery & charger sold separately | Battery & charger included |
| Runs on | Two 2s–3s LiPo packs or two 7-cell NiMH packs | A 2s–4s LiPo | Included battery |
| Ready to run | $724.85completer 2990 + AA | $574.85completer 2996X + AA | $184.90+ AA |
| Links | You’re here | View | View |
Specs as Traxxas prints them. Ready to run = the vehicle + the completer pack (battery and charger in one box) listed for that model + AA batteries for the transmitter, at our prices today; other battery options are on each model’s page. Nitro models also need fuel, bought locally. New to RC? How to read this table
Parts & upgrades
Keep your Spartan SR running.
Genuine Traxxas replacement parts and upgrades, organized by part number.
Traxxas · Model 103076-4
Manuals, parts list & exploded views
Spartan SR · Open the original manufacturer documents, hosted by RC Hobby Shop.
Parts list
User manual
Complete original documents, including safety instructions. Files open in a new tab.
